SHIP’S NAME	ADAMOON
EX.NAME	REGALICA
CALL SIGN	A 8 Z Q 5
PORT OF REGISTERY FLAG	MONROVIA LIBERIA
BUILD PLACE / YEAR	TAIZHOU SANFU SHIP ENGINEERING CO LTD. CHINA
IMO NO	9521758
MMSI NO	636015272
CLASS / NO	B.V – 40927N
P&I	SSM STEAMSHIP MUTUAL
HULL&MACHINERY	ALIANZ GROUP
TYPE OF SHIP	GENERAL CARGO
SEA SPEED/CONSP	BALLAST 12,5 KTS/13,5 MTN LOAD 11,75 KTS/14MTN
L.O.A.	149.96M
L.B.P.	140,80 M
MOULDED DEPTH/BREATH	12,50 M/23.60 M
AIR DRAFT	41,48M
GRT	13579 RT
NRT	6428 RT

SUEZ GRT/ NRT
PANAMA GRT REG.NO
LIGHT SHIP	6731T
T.P.C.	32,06
F.W.A.	205 MM
TOTAL BALLAST CAP.	7995 M³
TOTAL F/O CAP.	817,80 M³
TOTAL D/O CAP.	204,3 M³
TOTAL L/O CAP.	119,0 M³
TOTAL FW CAP.	242,7 M³
PROPELLER	PITCH LEFT HANDED
FREEBOARD BALLAST LADEN	7.80M 3.14M
HATCH COVER	MC GREGOR HYDROLIC
MAIN ENG.&POWER	STX-MAN 5S50MC 6570KW 8810 HP
GEN.& POWER	2×548 KW 1×680 KW
BOW THRUST. POW.	600KW 805HP
SHAFT GEN.& POW	NIL
EMG.GEN.& POW	140 KW

CRANES	NO1 30MTS/1 GRAB
	NO2 30MTS/1 GRAB
	NO3 30MTS/1 GRAB

HOLD DIMENSIONS TT	NO1 19.2×11.2F 19.7Ax10.8
	NO2 21.6×19.7×10.8
	NO3 21.6×19.7×10.8
	NO4 21.6×19.7×10.8
	NO5 20.0x 19.7F 12.5A x10.8

HATCH DIMENSIONS	NO1 12.8×12.8×1.95
	NO2 14.4×19.7×1.95
	NO3 14.4×19.7X1.95
	NO4 14.4×19.7×1.95
	NO5 14.4×19.7×1.95

HOLD TANK TOP STR	20 MT/M2

HATCH TT	2.50MT/M2

MAIN DECK TT	3MT/M2

LOAD LINE	FREEBOARD (M)	DRAFT (M)	DISP. (T)	DEADWEIGH (T)
SUMMER	3,145	9,387	26313,01	19581,01
TROP FW	2,745	9,787	26929,21	20198,21
FRESH WATER	2940	9,592	26314,47	19583,47
TROPICAL	2950	9,582	26940,10	20209,10
WINTER	3,340	9,192	25688,82	18957,82
COMPARTMENT	GRAIN M³	GRAIN CBTF	BALE M³	BALE CBTF
HOLD NO 1	3445,90	121689
HOLD NO 2	4744,90	167567
HOLD NO 3	4744,90	167567
HOLD NO 4	4793,10	169268
HOLD NO 5	4463,40	157626
TOTAL	22192,4 m³	783717
